Aquablend® eSQX™ Touch Free – On Demand Sensor Front of Wall Component with Custodian® Basin Outlet
Product Information
Aquablend® eSQX™ is Australia’s first and most technically advanced touch-free thermostatic mixer solution. Designed to deliver touch-free pre-mixed warm water for enhanced infection control and crosscontamination prevention. The solution includes an infra-red sensor located above Custodian® basin outlet.
- On Demand Sensor - place hand in front of sensor to turn on, valve stays open without hand remaining in the sensor range. Place hand in front of sensor again to turn off
- Low voltage 12V mains power supply
- Custodian® anti-ligature basin outlet
- Flush cycle stagnation management to reduce risk of bacterial growth, usage monitoring and other function settings are adjustable via Oras App and Bluetooth connectivity
- Effective reduction of Legionella risk
- Compatible with Smartflow Monitoring System for TMV monitoring and reporting
- Smart, durable easy-clean chrome surfaces
- IP67 rated connections
- Faceplate can be removed to access integral isolation/check valves, strainers and inspection ports
- Requires In-Wall Component ATM621
- Smart Flow Enable
- NSW Health Approved
- Watermark: AS 4032.4 WMKA25301
Sensor
| Sensor Range | 20-100mm (Factory default setting - adjustable) |
Time Flow
| Water Run Time | 15 secs (+/-1) after activation (Factory default setting - adjustable) |
Power Source
| Power Supply | 12VDC |
| Product Code | Description | |
|---|---|---|
| ATWM-CNBSN | Aquablend® eSQX™ Touch Free – On Demand Sensor Front of Wall Component with Custodian® Basin Outlet – 12V Mains – Custodian Basin Outlet 8Lpm Aerator | Add to spec |
