Concealed Spindle Right Angle Cistern Tap male and female 15mm
Product Information
Concealed spindle tapware series is robust and vandal resistant. The ergonomically designed handle features a dress skirt which conceals the anti-vandal handle fixing and spindle. Ideal for commercial, institutional and public amenity applications.
- High quality construction from dezincification resistant (DR) brass with durable chrome plated finish
- Vandal-resistant internal locking ring secures the handle and requires the supplied special key to release
- Serviceable with all wearing components replaceable, thus providing an even longer life
- Blue (Cold) indicator button supplied standard. Yellow (Warm) and Red (Hot) available on request - specify when ordering.
- Heavy duty bright chrome
- WaterMark: AS/NZS 3718 WMKA 1583 SAI Global
Pressure
| Ceramic Disc Maximum Static Pressure | 800kPa |
| Ceramic Disc Minimum-Maximum Working Pressure (AS/NZS 3500) | 50-500kPa |
Temperature
| Ceramic Disc Maximum Working Temperature | 85C |
Jumper Valve
| Jumper Valve Maximum Static Pressure | 1200kPa |
| Jumper Valve Maximum Working Temperature | 95C |
| Jumper Valve Minimum-Maximum Working Pressure (AS/NZS 3500)* | 30-500kPa |
| Product Code | Description | FINISH | VALVE | PRIMARY FLOW RATE | |
|---|---|---|---|---|---|
| CS303 | Concealed Spindle Right Angle Cistern Tap male and female 15mm – Jumper Valve | Chrome Plating | Jumper Valve | 8L/minute | Add to spec |
