Wall Mounted Sensor Tap – Hands-Free – Active Sense with Custodian® Basin Outlet
Product Information
The Touch Free Wall Mounted Sensor is a sensor operated, hands-free tap that is installed above sinks and basins. It operates by sensing a hand in front of the sensor unit. It uses a beam of invisible Infrared light which, when reflected from hand back to the sensor, operates the unit.
- To turn tap on, place hand under spout in front of sensor
- To turn tap off, move hand away
- Valve stays open for 6 seconds, or as long as the hand is within sensor range
- Maximum flow time of 45 seconds* per activation reduces waste and prevents vandalism
- Equipped with automatic hygiene flush function (1-10min/24hr) - enabled on request
- Stainless steel sensor plate
- Spout has anti-rotation pin and high Security Torx grub screw, designed to exceed anti-ligature requirements of TS001-2013
Inlet & Outlet
| Inlet Connection | 15 mm (1/2”) BSP |
Pressure
| Recommended Working Pressure | 100 - 500 kPa |
Flow Rate
| Flow Rate | 8 lpm supplied standard. 5 lpm available on request. |
Temperature
| Maximum Temperature | 70 °CC |
Power Source
| Operating Voltage | 24V DC |
| Maximum Current | 1A |
| Power Consumption | Less than 10W |
Sensor
| Sensor Range | Sensor Min / Max Ambient Temperature: Minimum: -5 °C, Maximum: 50 °C |
| Sensor Range | 100 - 235 mm |
IP Rating
| Sensor Protection Rating | IP67 for the front panel and sensor lens. No IP rating behind panel. |
Time Flow
| Flow Time | Runs as long as hand is within range. (Active Sense) When out of range, runs for 6 seconds. (Afterfl ow) Maximum continuous fl ow period per sensor activation is 45 seconds. (Security Time Out) |
| Product Code | Description | |
|---|---|---|
| DET5071A-CNBSN | Wall Mounted Sensor Tap – Hands-Free – Active Sense with Custodian® Basin Outlet – With Custodian Basin Outlet | Add to spec |
