Aquablend® SQX® Sink Mixer with Extended Handle
Product Information
Aquablend® SQX® delivers the world’s highest standard of performance and quality, Certified to AS/NZS 4032.4–2005 providing Australia’s market leading compliant solution to meet the demands of AS/NZS 3500 for heated water temperature control. Thermostatic mixing at the point of use can provide reduced risk of legionella and other water-borne bacteria, improving water system health. Designed to for easy installation and efficient maintenance the range also has outstanding user benefits, providing comfort and control, scald protection and both water and energy efficiencies beyond those of traditional tapware. Designed ergonomically for people with disabilities and for surgical and clinical hand washing the SQX range is ideal for any Hospital, Care or Commercial installation.
- Compliant to AS4032.4 and NSW Health Approved
- Point of use Thermostatic with sequential operation for energy efficient flow and temperature control
- Fixed / swivel spout
- Pressure compensating laminar flow supplied as standard reduces airborne water droplets that may carry bacteria
- Longer lever, designed for elbow control in health applications or for easier use in accessible applications
- Cool to touch and non-conductive mixer body
- Colour indication on handle for easy identification
- Easy to clean design
- Serviceable in-situ with all maintenance parts accessible above the basin
- Australian designed and manufactured
- WaterMark: AS 4032.4 WMKA25301
- NSW Health Approved
Colours
| Hot Inlet Temperature Range | Min 55°C Max 85°C |
| Cold Inlet Temperature Range | Min 5°C Max 25°C |
| Adjustable Temperature Range | Cold to 46°C |
Pressure
| Operating Working Pressure | 20 - 500 kPa |
| Dynamic Inlet Pressures | Min 20kPa Max 500kPa For optimum operation it is recommended that the hot and cold water supply pressures be balanced within +/- 10% |
Inlet & Outlet
| Inlet Connection | 15mm (1/2” BSP) |
| Product Code | Description | |
|---|---|---|
| ATM607D-5 | Aquablend® SQX® Sink Mixer with Extended Handle – SQX Sink Mixer with Extended Handle 6 lpm | Add to spec |
| ATM607D-6 | Aquablend® SQX® Sink Mixer with Extended Handle – SQX Sink Mixer with Extended Handle 5 lpm | Add to spec |
