Aquablend 1500 TMV – Lift Lever Thermal Flush -350×350 SS cabinet – HW/CW/CW BYPASS/WW pipes at bottom

• Lift Lever Thermal Flush activation incorporated within the headworks for faster, safer, more efficient thermal disinfection capabilit
• Manufactured from Lead Free brass components - including bypass fittings
• Scald and thermal shock protection with rapid thermal shut-off should either the cold or hot water supply fail
• Highly responsive temperature control, maintaining outlet temperature within +/- 2°C under changing inlet temperature and pressure conditions
• Delivers high flow at low pressure loss
• Supplied complete with isolating valves, non-return valves and dual stage strainers incorporating temperature/ pressure test ports
• Cold Water bypass provides cold water isolation valve for adjacent connected fixtures, within the cabinet space
• Pipework is designed to reduce flow restrictions and minimise bacterial capture points to reduce the risk of bacterial contamination
• Flexible installation - can be upside down or sideways, inlet and outlet connections may be rotated to suit pipework design
• A range of suitable Stainless Steel lids are available for this model: - ATMSHL-350 - Hinged Lid with wall flange - ATMSXP-350 - Exposed Lid - ATMSSEC-350 - Secure/Heavy Duty Lid
• Standards licensed to AS4032.1 - Thermostatic Mixing Valves
• NSW Health Approved
