Sydney Water HYDRUS Ultrasonic Cold Water Meter
Product Information
Static ultrasonic water meter for accurate measuring and recording for all cold water applications.
- Open metering telegram
- Long-term stability under difficult conditions
- Leak detection
- Higher performance than class 2 requirements
- No calming sections required
- No measurement of air
- Design minimises sedimentation
- Mounting in any installation position
- Battery lifetime up to 16 years
- IP 68 permanent immersion
- Suitable for outdoor installation
- Displaying of error and alarm codes
- No over-run performance
- No magnetic influence
- Data logger for consumption values
Colours
| Medium temperature range | 1 - 50°C |
| Temperature safety | 1 - 90°C |
| Ambient operating temperature | 1 - 70°C |
| Ambient storage temperature | -20 - +50°C |
| Nominal pressure | 1600 kPa |
| Battery lifetime | Up to 16 years |
| Interfaces | Optical, radio 434 MHz |
| Data storage | For events and for consumption values |
| Approval | NMI R49, AS3565.1, AS3565.3 |
| Strainer | Included |
| Check Valve | Dual Check |
| Couplings | 2 included |
| Accuracy class | 2 |
Power Source
| Power Supply | Two 3.6 VDC lithium batteries |
IP Rating
| Protection Class | IP 68 |
| Product Code | Description | |
|---|---|---|
| EHM5020SW | HYDRUS Ultrasonic Cold Water Meter – DN20 Sydney Water Standard, Dual Check Valve including nut and tail connections | Add to spec |
