Slimline 4 Way Bench Mounted Laboratory Tap (Dry Media)
Product Information
Enware’s Slimline laboratory outlets are supplied with a tapered tube nozzle and are assembled for each specific media type. The durable powder coat finish gives significant protection against corrosion, discolouration and surface damage. Slimline handles are ergonomically designed for precise feel and finger tip control. Handles are colour coded for easy service identification and use complimentary buttons.
- Suited for dry media up to technical gas level 2.0 (with isolation), 4.0 (without isolation) and higher upon request
- Teflon needle valve with stainless steel seat
- Durable powder coat finish
- Handle and indicator button identification to suit specified media
- 1/2” BSP male inlet tail with 1/4” BSP female thread connection
- Tube nozzle
- Optional integral isolation/ service valve
Inlet & Outlet
| Inlet Connection | 1/2” BSP Male, 1/4” BSP Female |
| Outlet Connection | Tube Nozzle, 3/8” BSP Female (without nozzle) |
Pressure
| Maximum Working Pressure – Needle Valve | 700 kPa (dry media)kPa (Burning GA |
| Maximum Testing Pressure | 1000 kPakPa |
Gas
| Burning Gas Options | Argon, Carbogen, Carbon Dioxide, Compressed Air, Helium, Hydrogen, Nitrogen, Nitrous Oxide, Oxygen, Vacuum. Note: Client to specify media type |
| Product Code | Description | |
|---|---|---|
| LCN148N | Slimline 4 Way Bench Mounted Laboratory Tap (Dry Media) – Needle Valve | Add to spec |
| LCN148NI | Slimline 4 Way Bench Mounted Laboratory Tap (Dry Media) – Needle Valve with Integral Isolation Valve | Add to spec |
