ComLab: Bench Mounted Laboratory Mixing Set with Swivel/Fixed Gooseneck Outlet – Ceramic Disc – Water
Product Information
Enware’s Slimline laboratory outlets are supplied with a tapered tube nozzle and are assembled for each specific media type. The durable powder coat finish gives significant protection against corrosion, discolouration and surface damage. Slimline handles are ergonomically designed for precise feel and finger tip control. Handles are colour coded for easy service identification and use complimentary buttons.
- 3/4 Turn Ceramic disc headworks provides precise flow control
- Durable white epoxy powder coat finish
- Green Handle and indicator button identification to DIN EN13792
- Swivel high-rise swivel spout with integral fixing option
- 1/2” BSP male inlet tails with backnuts for bench mounting
- Tube nozzle outlet with Flow Control and Check Valve. 3/8"BSPFI when removed
- Lead Free Brass
Inlet & Outlet
| Inlet Connection | 1/2” BSP Male |
| Outlet Connection | Tube Nozzle, 3/8” BSP Female (without nozzle) |
Pressure
| Working Pressure Range – Ceramic Disc | 20 - 700 kPa* (Water) |
| Maximum Testing Pressure | 1000 kPakPa |
Temperature
| Working Temperature Range | 0 - 90 °C |
| Water Options | Cold, Hot Note: Client to specify media type |
| Product Code | Description | FINISH | VALVE | PRIMARY FLOW RATE | |
|---|---|---|---|---|---|
| LCN113 | Slimline Bench Mounted Laboratory Mixing Set with Swivel Gooseneck Outlet – Ceramic Disc – Water Only | Powder Coating | Ceramic Disc | 6L/minute | Add to spec |
