ComLab 90 Degree Fume Cupboard Outlet – 155mm Reach with Quick Connections
Product Information
Enware’s ComLab Fume Cupboard fittings are available in a wide range of connection types. Outlets are colour coded for easier identification with media type.
- The durable powder coat finish gives significant protection against corrosion, discolouration and surface damage
- Outlet colour identification to match media control; back plate is zone 1, middle ring is zone 2 and front ring is zone 3
- Tube nozzle with dual check valve (for water)
- 6 L/min regulator (for water)
- Specify media type when ordering
- Quick Connect inlet connections for 8mm flexible tube
- WaterMark: AS/NZS 3718 WMKA 1583
Pressure
| Working Pressure Range | 20 - 700 kPa* (Water) |
Temperature
| Working Temperature Range | 0 - 90 °C |
Inlet & Outlet
| Outlet Connection | Tube Nozzle 3/8” BSP Female (without nozzle) |
| Inlet Connection | Quick Connect (to suit 8mm flex tube) |
Flow Rate
| Flow Rate | 6 L/min (for water |
